Description

The BT500 BDAC Belt-Driven Compressor is a top-tier industrial air station designed for heavy-duty manufacturing, large-scale automotive centers, and intensive pneumatic operations. Combining a massive 500-liter storage tank with a high-torque 10HP motor, this unit is built to deliver a continuous, high-volume air supply without the performance drops seen in smaller units.

Below are the key features that define this industrial workhorse:

1. High-Performance 10HP Industrial Motor

• Heavy-Duty Power: The $10\text{ HP}$ ($7.5\text{ kW}$) induction motor provides massive torque, specifically designed to drive the large 3-piston pump head at optimal efficiency.

• Reliable Drive: Built for high-duty cycles, the motor is capable of running for extended periods, making it suitable for factory floors and 24/7 service centers.

2. Professional 3-Piston Pump Head

• Triple-Cylinder Compression: The 3-piston configuration allows for massive air displacement and rapid tank recovery.

• Slow-Running RPM: The belt-drive system reduces the pump’s rotational speed. This minimizes friction and heat, significantly extending the life of the pistons, rings, and valves.

• Cast Iron Durability: The pump is constructed with heavy-duty cast iron cylinders to withstand the extreme thermal stress of high-pressure air generation.

3. Massive 500-Liter Air Reservoir

• Ultimate Buffer: The 500L tank provides an enormous reserve of compressed air, allowing you to run high-consumption tools (like sandblasters or multiple spray guns) simultaneously without the motor constantly cycling.

• Consistent Pressure: A larger tank acts as a natural dampener, smoothing out pressure fluctuations and providing a steady flow to your machinery.

4. Advanced Thermal Management

• Large Cooling Flywheel: The oversized flywheel features integrated fan blades that force high-velocity air across the pump’s cooling fins.

• Aftercooler/Intercooler: Usually equipped with finned copper piping between cylinders to cool the air before it enters the tank, reducing moisture buildup.

5. Industrial Safety & Components

• Reinforced Belt Guard: A rigid steel safety cage protects personnel from the high-torque belt drive system.

• Dual-Stage Pressure Control: Includes a heavy-duty industrial pressure switch with a built-in unloader valve for smooth motor start-ups.

• Professional Filtration: Equipped with high-capacity air intake filters to ensure the internal components are protected from dust and debris in a workshop environment.

Technical Summary
